Specifications
| Type | Value |
|---|---|
| Housing Material | 301 STAINLESS STEEL |
| Screw Material | ZINC PLATED CARBON STEEL |
| Hex Screw (in) | 5/16" |
| Band Width (in) | 1/2" |
| Torque Range (in-lbs) | 25-37 |
| SAE | 36 |
| Min. Dia. (in) | 1-13/16 |
| Max. Dia. (in) | 2-3/4 |
| Min. Dia. (mm) | 46 |
| Max. Dia. (mm) | 70 |
Cross References
| Name | Part Number | Type |
|---|---|---|
| Automann | 561.20036 | Aftermarket |
| Automann | 56120036 | Aftermarket |
| Breeze | 62036 | Aftermarket |
| Breeze | 62036H | Aftermarket |
| Breeze | 62036HC | Aftermarket |
| Excoh | 4SCH036 | Aftermarket |
| Gates | 32036 | Aftermarket |
| Murray | H3600C | Aftermarket |
| Tectran | HC36 | Aftermarket |
| Velvac | 022336 | Aftermarket |
Application
| Type | Details |
|---|---|
| Application | Coolant, Fuel & Air Hoses |
| Clamp Type | Lined Worm Gear Hose Clamp |
| Clamping Range | 1-13/16 in to 2-3/4 in (46–70 mm) |
| Fitment | Universal fit within the stated size; confirm against your OEM or interchange part number. |
Product Overview – Lined Clamp 1.81 in to 2.75 in
The Lined Clamp 1.81 in to 2.75 in (Part No. OTX-4SCH036) is a lined worm gear hose clamp with a clamping range of 1-13/16 in to 2-3/4 in (46–70 mm), made for coolant, fuel and air hoses on trucks, buses and off-highway equipment.
A smooth band underside reduces hose damage while keeping the convenience of a standard worm gear clamp.
Construction: a 301 stainless steel band 1/2 in wide, a zinc plated carbon steel screw with a 5/16 in hex, with a torque rating of 25-37 in-lbs.
It interchanges with 9 aftermarket part numbers from brands such as Automann, Breeze, Excoh, Gates, including Automann 561.20036, Excoh 4SCH036, Gates 32036.
Distributors and fleet buyers can request volume pricing on OTX-4SCH036 from OneTouch Exim by email or WhatsApp.
Frequently Asked Questions
Which part numbers does OTX-4SCH036 replace?
OTX-4SCH036 interchanges with Automann 561.20036, Breeze 62036HC, Breeze 62036, Breeze 62036H, Excoh 4SCH036, Gates 32036 and more. The cross reference table lists all 10 matching numbers.
What hose size does OTX-4SCH036 fit?
It fits hoses with an outside diameter from 1-13/16 in to 2-3/4 in (46–70 mm).
Manufacturer names and part numbers are used for reference and interchange purposes only. No affiliation with, or endorsement by, these manufacturers is implied.
