SpecificationsCross ReferenceApplicationOverview
Specifications
| Type | Value |
|---|---|
| Nominal Diameter (Ø) (in) | 10.38 |
| Insert Thickness (A) (in) | 0.077 |
| Insert Apex Width (B) (in) | 0.104 |
| Insert Depth (C) (in) | 0.281 |
| Band Thickness (D) (in) | 0.062 |
| Band Width (E) (in) | 0.875 |
Cross References
| Name | Part Number | Type |
|---|---|---|
| Automann | 561.291040-B | Aftermarket |
| Automann | 561291040 | Aftermarket |
| Automann | 561291040B | Aftermarket |
| Breeze | 0373 0104 264 | Aftermarket |
| Breeze | 03730104264 | Aftermarket |
| Cummins | 2871861 | OEM |
| Cummins | Q187680 | OEM |
| Donaldson | P238307 | Aftermarket |
| Dorman | 674-7000 | Aftermarket |
| Dorman | 6747000 | Aftermarket |
| Excoh | 4VC1038 | Aftermarket |
| Freightliner | FLT2871861 | OEM |
| Grand Rock | DPFVB-001 | Aftermarket |
| Grand Rock | DPFVB001 | Aftermarket |
| Nelson Exhaust | AC300012 | Aftermarket |
| New Star | S-25704 | Aftermarket |
| New Star | S25704 | Aftermarket |
| Norma | 3730104264 | Aftermarket |
| R.G. Ray | 100279-004 | Aftermarket |
| R.G. Ray | 100279004 | Aftermarket |
Application
| Type | Details |
|---|---|
| Application | DPF / Aftertreatment |
| Clamp Type | V-Band Clamp |
| Compatible With | Cummins ISB, ISB 6.7, Paccar PX6, Cummins Paccar |
| OEM Makes | Cummins, Freightliner |
| Nominal Diameter | 10.38 in (263.7 mm) |
Product Overview – DPF V-Band Clamp 10.38 in
The OTX-4VC1038 V-band clamp (10.38 in (263.7 mm)) is engineered for DPF and aftertreatment joints that see high heat, vibration and frequent service, and it is compatible with Cummins ISB, ISB 6.7, Paccar PX6, Cummins Paccar.
In the aftertreatment system it holds the diesel particulate filter (DPF) sections together and allows fast removal when the filter needs cleaning or replacement.
Measured dimensions: a 0.875 in band width, a 0.077 in insert thickness, an insert depth of 0.281 in; compare these with your original clamp before ordering.
Buyers searching for Cummins 2871861, Cummins Q187680 can use OTX-4VC1038 as a direct interchange; the full list of 14 matching numbers is shown below.
Tip: always match the clamp size to the outside diameter of the joint, not the pipe or hose inside diameter.
Order the OTX-4VC1038 from OneTouch Exim in single units or bulk cartons; share your quantity and destination for a quick quote.
Frequently Asked Questions
Which part numbers does OTX-4VC1038 replace?
OTX-4VC1038 interchanges with Cummins 2871861, Cummins Q187680, Freightliner FLT2871861, Automann 561.291040-B, Automann 561291040, Breeze 0373 0104 264 and more. The cross reference table lists all 20 matching numbers.
What size is the OTX-4VC1038 V-band clamp?
It has a nominal diameter of 10.38 in (263.7 mm).
Manufacturer names and part numbers are used for reference and interchange purposes only. No affiliation with, or endorsement by, these manufacturers is implied.
